API609 WCB Cast Steel Worm Gear Large Bore Flanged Butterfly Valve

Product Overview

The API609 WCB Cast Steel Worm Gear Large Bore Flanged Butterfly Valve is a heavy-duty industrial large-diameter pipeline control valve manufactured in strict accordance with American API609 Category B standards. The entire valve body is precision cast from standard ASTM A216 WCB carbon steel, featuring high structural strength, pressure resistance and high-temperature stability, solving the deformation and cracking problems of ordinary cast iron valves under large-diameter high-flow working conditions. Adopting professional worm gear turbine transmission structure, it realizes labor-saving slow opening and closing with self-locking positioning function, effectively avoiding disc flutter and medium impact in large-caliber pipelines.

This large bore flanged butterfly valve fully complies with ASME B16.5, ASME B16.10 and API598 specification standards, with complete ANSI Class150 and Class300 pressure grades. It supports soft seal and hard seal dual sealing forms, covering low-temperature zero-leakage and high-temperature anti-abrasion working scenarios. Widely applicable for large-diameter main pipelines in thermal power, petrochemical, municipal water supply and heavy industrial systems, it is a reliable heavy-duty isolation and flow regulation valve for large-scale engineering projects.

Core Product Features

1. Standard WCB Cast Steel Heavy-Duty Body
The valve body is integrally cast from ASTM A216 WCB carbon steel, with dense internal structure and no casting defects. It maintains excellent mechanical stability in the working temperature range of -29℃ to 425℃, effectively resisting pipeline pressure impact and structural deformation. Compared with ductile iron valves, WCB cast steel has stronger high-temperature resistance and load-bearing capacity, suitable for harsh large-diameter industrial pipeline working conditions.

2. Worm Gear Turbine Self-Locking Operation
Equipped with high-precision worm gear reducer, the large-bore valve can be opened and closed labor-savingly through manual handwheel. The built-in self-locking structure can fix the valve plate at any opening angle, preventing arbitrary shaking caused by high-flow medium impact. It avoids the safety hazards of sudden opening and closing of large-diameter valves, ensuring stable and adjustable pipeline flow.

3. Full API609 American Standard Compliance
Designed and produced strictly in accordance with API609 Category B large butterfly valve specifications, matching ASME B16.5 flange dimension, ASME B16.10 face-to-face length and API598 hydrostatic test standards. All products pass strict factory pressure sealing tests, fully meeting the acceptance requirements of American standard large-scale engineering and international bidding projects.

4. Large Bore Specialized Pipeline Design
Standard size range covers NPS12"–NPS64" (DN300–DN1600), supporting customized super-large diameter DN1800–DN2400. Optimized internal flow channel design reduces medium flow resistance and turbulence loss, perfectly adapting to high-flow transmission requirements of main pipelines in power plants, chemical plants and municipal waterworks.

5. Dual Sealing Options for Diversified Working Conditions
It provides soft resilient seat and metal hard seat two sealing solutions. EPDM/NBR/Viton soft seat achieves ANSI Class VI zero leakage for water and low-temperature oil medium; Stellite hard alloy overlay metal seat adapts high-temperature, high-pressure and abrasive medium, realizing long-term stable sealing of large-diameter valves under complex working conditions.

6. Standard ANSI Flange Connection Structure
Adopts ANSI B16.5ASME B16.47 standard raised face double flange end, with accurate hole spacing and uniform specifications. It can be perfectly matched with American standard large-diameter pipeline flanges, featuring firm connection, strong vibration resistance and no loose leakage during long-term high-flow operation.

7. Anti-Corrosion & Wear-Resistant Configuration
The WCB valve body is treated with high-temperature anti-rust epoxy coating to resist atmospheric corrosion and medium erosion. The valve stem is made of high-strength stainless steel with anti-jamming design. Equipped with multi-layer composite high-temperature packing, it ensures reliable external sealing and stable long-term operation of large-diameter valves.

Technical Specifications

Installation, Operation & Maintenance Notes

1. Standard Operation Guidelines
This API609 WCB large bore butterfly valve is suitable for full open/closed isolation and stable flow regulation of large-diameter main pipelines. Long-term small-opening throttling is prohibited to prevent high-speed medium scouring and damage to the sealing pair. Operation beyond rated pressure and temperature limits is forbidden to avoid WCB material fatigue and sealing failure.

2. Professional Large Bore Flange Installation
Install the valve on the straight pipe section of the main pipeline, keep away from pump outlets, elbows and turbulent flow areas. Align the valve flange with the pipeline ANSI standard flange, install high-strength gaskets, and tighten bolts diagonally and evenly to ensure uniform stress. Clean welding slag and hard impurities inside the pipeline before installation to prevent scratching the sealing surface.

3. Worm Gear Transmission Maintenance
Regularly inject special lubricating grease into the worm gear box every 3–6 months to ensure flexible transmission and labor-saving operation. Check the self-locking function regularly to avoid positioning failure caused by gear wear. Do not apply violent force to the handwheel to prevent gear deformation and structural damage.

4. Daily Sealing & Structural Inspection
Regularly check the wear and aging of the valve seat and packing parts. Replace damaged accessories after full pipeline depressurization and medium drainage. Inspect the WCB valve body and flange connection regularly to ensure no leakage and structural stability during long-term continuous operation of large-flow pipelines.

Wide Application Scenarios

• Thermal Power & Energy Industry: Power plant large-diameter circulating water pipelines, boiler auxiliary flue gas and waste water main pipeline isolation valves

• Petrochemical Refinery Projects: Crude oil and refined oil large-diameter transmission main pipelines, low-pressure chemical medium circulating systems

• Municipal Water Supply & Sewage Treatment: Urban raw water delivery trunk pipes, super-large sewage treatment plant large-bore pipe network control valves

• Metallurgy & Heavy Industry: Factory large-scale circulating water systems, process waste liquid and industrial gas large-diameter pipeline equipment

• Industrial Centralized Heating & HVAC: Industrial park large-caliber hot water circulation main pipelines, heavy-duty ventilation and exhaust pipeline valves

Product Competitive Advantages

✅ Premium WCB Cast Steel Body — ASTM A216 standard cast steel structure, high temperature and pressure resistant, anti-deformation for heavy-duty large bore pipeline conditions.

✅ Worm Gear Self-Locking Drive — Labor-saving operation, stable positioning, effectively solving disc flutter problem of large-diameter high-flow valves.

✅ Full API609 American Standard Compliance — Complete ASME standard specifications, compatible with global ANSI large-scale industrial pipeline projects.

✅ Ultra-Large Caliber Coverage — Standard DN300-DN1600, customizable super-large size to meet special engineering large-bore pipeline demands.

✅ Dual Soft & Hard Seal Optional — Flexible sealing solutions to adapt low-temperature zero leakage and high-temperature wear-resistant working conditions.

✅ High Stability & Low Failure Rate — Reinforced flange structure + anti-corrosion treatment, suitable for long-term continuous heavy-load operation.

Order & Certification Information

MOQ: 1 Unit
Production Lead Time: 15–25 working days for standard large sizes, 30–45 working days for customized super-large caliber
Supporting Documents: EN10204 3.1 WCB Material Certificate, API598 Test Report, ISO9001 Quality Certificate, Factory Inspection Report
Export Packaging: Internal anti-rust treatment + Plastic wrap + Reinforced fumigation-free wooden case for large valve
Warranty Service: 12-month quality warranty + lifelong professional after-sales technical support

Contact Us for customized special sizes, pressure grades, sealing types and bulk preferential prices of API609 WCB Cast Steel Worm Gear Large Bore Flanged Butterfly Valves.
