API609 Worm Gear Manual Limit Switch Resilient Seated Wafer Butterfly Valve

Product Overview

The API609 Worm Gear Manual Limit Switch Resilient Seated Wafer Butterfly Valve is a standard American quarter-turn manual industrial butterfly valve manufactured strictly in accordance with API609 industrial specifications. Adopting classic wafer clamped connection structure and high-performance resilient soft seated sealing design, this valve achieves ANSI Class VI zero leakage shutoff performance, solving the leakage pain point of traditional hard-seal butterfly valves for conventional clean media. Equipped with a professional worm gear turbine transmission mechanism, it realizes labor-saving manual opening and closing operation with stable self-locking positioning function.

Different from ordinary manual butterfly valves, this model is equipped with a precision mechanical limit switch device, which can accurately control the full-open and full-closed stroke of the valve plate, effectively avoiding over-travel operation and sealing surface damage. All dimensional standards, pressure grades and hydrostatic tests comply with ASME B16.10, ASME B16.5 and API598 regulations. Featuring compact structure, easy installation and reliable sealing, it is widely used in petrochemical, thermal power, municipal water supply and general industrial pipeline shutoff and flow control systems.

Core Product Features

1. Full API609 American Standard Compliance
Designed, produced and inspected in strict accordance with API609 Category B butterfly valve standards, matching ASME B16.10 face-to-face dimension and ASME B16.5 Class150 pressure specifications. All finished valves pass API598 shell pressure test and zero-leakage sealing test, fully meeting American standard industrial pipeline engineering requirements and international project acceptance standards.

2. Worm Gear Turbine Labor-Saving Operation
Equipped with high-quality cast iron worm gear box, the self-locking turbine structure greatly reduces manual operating torque, realizing labor-saving opening and closing for large-diameter valves. The built-in self-locking function fixes the valve plate at any opening angle to prevent shaking and displacement caused by medium flow impact, ensuring stable pipeline flow control.

3. Precision Mechanical Limit Switch Device
Customized matched limit switch assembly can accurately limit the valve’s full open and full closed positions, preventing excessive rotation from damaging the soft seal seat. The mechanical limit structure is durable and not affected by medium pressure and environmental changes, effectively improving valve operation accuracy and prolonging sealing service life.

High-Performance Resilient Soft Seal Zero Leakage
Adopts integrated elastic soft seat (EPDM/NBR/Viton) design, with good compression resilience and fitting performance. It achieves ANSI Class VI bubble-tight zero leakage shutoff, perfectly suitable for water, gas, fuel oil and non-corrosive medium pipelines, solving the leakage problem of traditional industrial butterfly valves.

4. Compact Wafer Clamped Installation Structure
Standard American wafer type structure with ultra-short structural length, no need for extra flanges during installation. The valve is directly clamped between two pipeline flanges, featuring simple construction, firm clamping and strong vibration resistance, saving pipeline space and overall engineering installation cost.

5. Standard ANSI Class150 Pressure Grade
Optimized valve body wall thickness and structural design, stable operation under ANSI Class150 rated pressure. The overall structure undergoes finite element pressure analysis to ensure no deformation or leakage under long-term pipeline pressure fluctuation, adapting to conventional medium-pressure industrial pipeline working conditions.

6. Durable & Low Failure Rate Structure
The valve disc adopts stainless steel anti-corrosion treatment, with smooth surface and anti-scouring performance. The worm gear transmission parts are equipped with lubricating structure for flexible long-term operation. The whole valve has simple structure, few vulnerable parts and low later maintenance cost.

Technical Specifications

Installation, Operation & Maintenance Notes

1. Standard Operation Guidelines
This API609 soft seal wafer butterfly valve is mainly used for pipeline full open and full closed isolation. Long-term small-opening throttling operation is prohibited to prevent high-speed medium scouring and damage to the resilient soft seat. Operate strictly within Class150 rated pressure and temperature range to avoid sealing failure.

2. Wafer Type Standard Installation
Install the valve on the straight pipe section of the pipeline, keep away from pump outlets and elbow turbulent areas. Align the valve center with the pipeline flange center, clamp the valve body evenly, and tighten bolts diagonally and symmetrically to ensure uniform stress. Clean pipeline welding slag and hard impurities before installation to protect the soft sealing surface.

3. Limit Switch & Worm Gear Maintenance
Regularly check the sensitivity and accuracy of the mechanical limit switch to ensure effective stroke limitation. Inject lubricating grease into the worm gear box every 3–6 months to keep transmission flexible and labor-saving. Avoid violent forced twisting of the handwheel to prevent gear and limit mechanism damage.

4. Daily Sealing Inspection
Regularly check the soft seat for aging, wear and deformation. Replace the sealing ring in time if leakage occurs. Check the valve body and flange clamping status regularly to ensure no medium leakage during long-term pipeline operation.

Wide Application Scenarios

• Petrochemical Industry: Conventional oil products, mild medium pipeline shutoff and flow control systems

• Thermal Power Plants: Power plant circulating water, auxiliary gas and water supply pipeline isolation valves

• Municipal Water Treatment: Urban water supply, sewage treatment and large-flow water pipeline control equipment

• General Industrial Factory: Factory circulating water, compressed air and public engineering pipeline valves

• Building HVAC System: Central air conditioning, heating and ventilation pipeline shutoff and regulating valves

Product Competitive Advantages

✅ Standard API609 American System — Fully compliant with API609 and ASME American standards, compatible with global Class150 standard pipelines.

✅ Precision Limit Switch Protection — Accurate stroke limit prevents misoperation and seal damage, greatly extending valve service life.

✅ Worm Gear Labor-Saving Operation — Self-locking turbine design, easy manual control, stable positioning without disc shaking.

✅ Soft Seal Zero Leakage Performance — High-elasticity resilient seat, ANSI Class VI zero leakage, excellent sealing effect.

✅ Space-Saving Wafer Structure — Compact clamped design, simple installation, saving pipeline space and construction cost.

✅ Stable & Low Maintenance — Mature structure, few vulnerable parts, durable performance and low later operating cost.

Order & Certification Information

MOQ: 1 Unit
Production Lead Time: 10–20 working days for standard specifications
Supporting Documents: Factory Test Report, API598 Inspection Certificate, ISO9001 Quality Certificate, Material Specification Sheet
Export Packaging: Internal anti-rust protection + Plastic wrap + Reinforced fumigation-free wooden export case
Warranty Service: 12-month quality warranty + lifelong professional after-sales technical support

Contact Us for customized sizes, seal materials and bulk preferential prices of API609 Worm Gear Manual Limit Switch Resilient Seated Wafer Butterfly Valves.
